Marine Gearbox HCT800 Main Data

Input speed

600-1800r/min

Reduction ratio

4.95、5.57、5.68、5.93、6.43

Trans. capacity

0.625kw/r/min

6.86

0.588kw/r/min

7.33

0.551kw/r/min

7.84

0.515kw/r/min

8.4

0.480kw/r/min

Control way

Push-and-pull flexible shaft, electrically, pneumatically

Rated thrust

140KN

Center distance

450mm

L×W×H

1056×1280×1425mm

Net weight

2700kg

Flywheel

SAE21、18、16

Bell housing

SAE00、0
