Marine Gearbox HC1200/1 Main Data
|
Input speed |
600-1800r/min |
||
|
Reduction ratio |
3.74、3.95、4.45 |
Trans. capacity |
0.93kw/r/min |
|
5 |
0.833kw/r/min |
||
|
5.25 |
0.695kw/r/min |
||
|
5.58 |
0.65kw/r/min |
||
|
Control way |
Push-and-pull flexible shaft, electrically, pneumatically |
||
|
Rated thrust |
140KN |
||
|
Center distance |
450mm |
||
|
L×W×H |
1096x1260x1270mm |
||
|
Net weight |
2500kg |
||
|
Flywheel |
Depend on engine flywheel |
||
|
Bell housing |
SAE00 0 |
||
