Marine Gearbox HC1250 Main Data
|
Input speed |
400-1800r/min |
||
|
Reduction ratio |
2.032、2.481、3.043、3.476 |
Trans. capacity |
0.919kw/r/min |
|
3.947 |
0.850kw/r/min |
||
|
Control way |
Push-and-pull flexible shaft, electrically, pneumatically |
||
|
Rated thrust |
140KN |
||
|
Center distance |
390mm |
||
|
L×W×H |
1155x1330x1435mm |
||
|
Net weight |
2200kg |
||
|
Flywheel |
Depend on engine flywheel |
||
|
Bell housing |
No |
||
