Marine Gearbox HC300 Main Data
|
Input speed |
700-2500r/min |
||
|
Reduction ratio |
1.5、1.87、2.04、2.23、2.54、3、3.53 |
Trans. capacity |
0.257kw/r/min |
|
4.1、4.47 |
0.2kw/r/min |
||
|
4.61 |
0.184kw/r/min |
||
|
4.94 |
0.147kw/r/min |
||
|
5.44 |
0.13kw/r/min |
||
|
Control way |
Push-and-pull flexible shaft, electrically, pneumatically |
||
|
Rated thrust |
50KN |
||
|
Center distance |
264mm |
||
|
L×W×H |
680×930×880mm |
||
|
Net weight |
680kg |
||
|
Flywheel |
12V135、12V150、SAE18、16、14 |
||
|
Bell housing |
12V135、12V150、SAE0、1 |
||
