Marine Gearbox MA125 Main Data
|
Input speed |
1500-3000r/min |
||
|
Reduction ratio |
2.03、2.46 |
Trans. capacity |
0.020kw/r/min |
|
3.04 |
0.018kw/r/min |
||
|
3.57 |
0.016kw/r/min |
||
|
4.05 |
0.014 kw/r/min |
||
|
4.39 |
0.013 kw/r/min |
||
|
4.7 |
0.011 kw/r/min |
||
|
Control way |
Push-and-pull flexible shaft, electrically, pneumatically |
||
|
Rated thrust |
5.5KN |
||
|
Center distance |
125mm |
||
|
L×W×H |
291×454×485mm |
||
|
Net weight |
115kg |
||
|
Flywheel |
SAE11.5、10 |
||
|
Bell housing |
SAE2、3、4 |
||
