MV100A(7°Down Angle) Marine Gearbox Main Data
|
Input speed |
1000-3000r/min |
||
|
Reduction ratio |
1.23、1.28、1.62、2.07 |
Trans. capacity |
0.10kw/r/min |
|
2.56 |
0.09kw/r/min |
||
|
2.87 |
0.08kw/r/min |
||
|
Control way |
Push-and-pull flexible shaft |
||
|
Rated thrust |
20KN |
||
|
Center distance |
0mm |
||
|
L×W×H |
485×508×580mm |
||
|
Net weight |
220kg |
||
|
Flywheel |
6135Ca SAE14 11.5 |
||
|
Bell housing |
6135Ca SAE1 2 3 |
||
