Marine Gearbox MA142 Main Data
|
Input speed |
1500-2500r/min |
||
|
Reduction ratio |
1.97、2.52、3.03 |
Trans. capacity |
0.030kw/r/min |
|
3.54 |
0.026kw/r/min |
||
|
3.95 |
0.023kw/r/min |
||
|
4.5 |
0.019kw/r/min |
||
|
5.06 |
0.016kw/r/min |
||
|
5.47 |
0.013kw/r/min |
||
|
Control way |
Push-and-pull flexible shaft, electrically, pneumatically |
||
|
Rated thrust |
8.5KN |
||
|
Center distance |
142mm |
||
|
L×W×H |
308×520×540mm |
||
|
Net weight |
140kg |
||
|
Flywheel |
SAE11.5、10 |
||
|
Bell housing |
SAE2、3 |
||
